The All New Fisherman 236 Center Console
Single Yamaha F300hp 4 stroke engine, Cruise 29.3MPH at 3900rpm, 9.7GPH
Center Line Length: 23ft7", Beam: 2.59m, Fuel: 435L long range tank, Passenger 10
Weight: inc 10 pax,fuel,water,gear plus engine: 5733lbs
WINNER!
THE HUTCHWILCO BOAT SHOW 2017, 'BEST BOAT IN SHOW' New Model 2017
Check out this 'Boat Test' Video on the
awesome Fisherman 236 Centre Console by 'Randy Vance' from
SPORT FISHING MAGAZINE USA
Just click on the picture here 'Left'
Main Specifications
BeamAmidships:8'6" (2.59m)
Center Line Length w/o Engine: 23'7" (7.18 m) (swim platforms not included)LOA w/Swim Platforms: 25'7" (7.80 m)
Bridge Clearance: 6'5" (1.96 m)
- w/T-top: 8'2" (2.49 m)
Cockpit Depth: 25" (0.64 m)
Hull Draft: 18.5" (0.47 m)
Transom Deadrise: 20 degrees (SeaV2® progression)
Maximum HP: 300 (224 kW)
Fuel Capacity - Standard: 115 gal. (435 l)
Passenger Capacity: 10
Weight w/o Engine: 3900 lb. (1769 kg)
Standard Features
Safety
Automatic bilge pump (1500 GPH) (5678 LPH) Basic flotation
Bow rail - low profile 316 grade stainless steel Captain Grady - digital boat systems and
operations guide for iPad and iPhone Cockpit toe rails
Composite stringer system & transom - water
impervious
Console grab rail
Nonskid fiberglass liner
Self-bailing cockpit w/cockpit drains (4) Stainless steel through-hull fittings
Cockpit & Deck
100% hand laid hull & deck
Battery select switch
Cleats - flush mount (pop up)
Cockpit freshwater shower (recessed) - 10-
gallon (38 l)
Cockpit lights - blue LED
Deck hardware - 316 grade stainless steel
through-bolted
Drink holders - stainless steel (8)
Factory engine pre-rigging
Fish box - 160-qt. (151.4 l) aft insulated box
Livewell - 15.5-gallon (58.7 l) aft insulated raw water livewell w/light, full column distribution inlet & ob drain (800 GPH pump) (3028 LPH)
Rod holders (4)
Rod storage racks - horizontal (6)
Rubrail - high density PVC w/stainless steel
insert
Seating - Lean bar w/backrest, flip-up bolster,
knife & pliers holder (1), tackle trays,
lockable storage & rod holders (4)
Seating - fold away aft bench seat w/cushion Seating - forward bolsters & port and starboard
fish box cushions
Seating - port and starboard cushioned bow
seating w/forward facing fold away bolstered
backrest (2)
Stereo system w/AM/FM tuner, MP3 auxiliary
audio connections, Bluetooth® & fold down
storage; speakers - bow (2) & helm (2) Stern eyes - 316 stainless steel
Storage - aft port swim platform storage Storage - aft starboard swim platform
Storage - forward anchor locker w/rode storage Swim platforms - aft port and starboard
extensions w/starboard ladder Transom door - fiberglass
Washdown - pressurized raw water w/hose
Console
Accessory outlet - 12V (2) Compass
Cooler/ice box - 29-qt. (27 l) insulated storage box under forward console seat
Drink holders - stainless steel (2)
Flush mount electronics area
Head - lockable console w/stand up head area,
indirect lighting, bulk storage & portable
head
Seating - molded forward console seat
w/cushion & backrest
Steering - hydraulic tilt
Steering wheel - 316 grade stainless
steel w/knob
Window - opening window w/screen
Windshield - scratch resistant acrylic windshield
w/handrail
w/ob drain
Fish box - 89-qt. (84.2 l) port forward insulated
fish box w/ob drain
Fish box - 89-qt. (84.2 l) starboard forward
insulated fish box w/ob drain
Fuel capacity - 115-gallon (435 l) tank Hydraulic trim tabs w/indicator & retractor International lighting
Optional Features
Options
Anchor windlass w/bow roller
Casting platform insert w/cushion
CE certification package
Cockpit bolsters
Cockpit step
Engine flush system w/hose attachment aft Engine paint - Yamaha factory-painted
engine(s), pearlescent white (300 HP and
350 HP only)
Head - portable w/deck pump out
Head - portable w/in-line macerator
Hull color - Celestial Blue, Coastal Fog Blue,
Sand, Sea Glass or Seaport Blue gelcoat;
Cape Gray or Harbor Blue paint
Outrigger kit - 15-ft. (4.6 m) crank outriggers T-
top mounted (requires T-top option) Outrigger kit - 15-ft. (4.6 m) radial T-top
mounted (requires T-top option)
Painted T-top frame (requires T-top option) Seating - Deluxe lean bar w/backrest, lockable
storage, rod holders (4), 25-gal. (95 l) insulated raw water livewell (under seat) w/light, full column distribution inlet & ob drain (800 GPH pump) (3028 LPH)
Ski pylon
Steering - power assist steering
T-top (fiberglass) w/integrated windshield, radio box, storage net, dome light, spreader light, rod holders (4), radar flat & outrigger plates (replaces standard console windshield)
T-top color - underside of fiberglass T-top (requires T-top option and matching gelcoat hull color option)
Windshield wiper
Canvas Options
T-top wing curtains (ivory)
